Harmoni - SmartFoil 140w/m² Mat - 7.0m², 980w

More from Foil Underfloor Heating Mat 140w/m² (Wood Finished Floors)

Harmoni - SmartFoil 140w/m² Mat - 7.0m², 980w
Harmoni - SmartFoil 140w/m² Mat - 7.0m², 980w
Harmoni - SmartFoil 140w/m² Mat - 7.0m², 980w
Harmoni - SmartFoil 140w/m² Mat - 7.0m², 980w
  • Lifetime warranty
  • Full earth protection
  • Ultra-thin heating cable
  • Twin conductor heating cable
  • Complete earth braiding
  • Suitable for under wood floor surfaces

View full description

Quick Find: 16387
Part Code: HMF140-7.0

Free Delivery Available
£98.36 exc VAT
RRP: £341.40
Stock Available: 6 Units

Selected Total: £0.00

    • + £53.88
    • + £54.70
    • + £30.49
    • None
    • + £45.98
    • + £80.83
    • + £76.94
    • + £83.82
    • + £46.50
    • + £48.00
    • + £79.91
    • + £78.00
    • + £78.00
    • None
    • + £99.49
    • + £130.57
    • + £123.84
    • + £89.99
    • + £89.99
    • None


    Day of Choice Delivery available after checkout

    Product overview

    Barcode 5060517176457
    Weight 4.40 Kg

    Please Note : Harmoni SmartFoil Underfloor Heating Mat Products must be used with XPS Insulation Boards.

    Harmoni SmartFoil is an ultra-thin electric radiant floor heating system primarily for use under laminate, engineered wood and glued hardwood.

    Uniform heating is achieved by the specialised materials used, which also eliminates problems due to hotspots or localised heating.

    This Harmoni Foil system is made with Fluoropolymer insulated heating cables. These are sandwiched between two layers of specially reinforced aluminium foil. The uniform spacing of the heating elements, further backed by the aluminium foil, ensures even heat distribution. The heating element is connected to a power-supply cable, which exits the laminate mat from one corner. The power lead is a flat thin two core flexible cord, consisting of two insulated conductors with a metal sheath and an outer sheath.

    Advantages of using Harmoni SmartFoil heating mats:

    • Ease of installation
    • Uniform heating of your laminate flooring: the specialised materials used eliminates problems due to hotspots or localised heating
    • Independently S Mark approved by Semko: visible proof of the safety of our product

    The Harmoni SmartFoil heating mat is designed for installation directly under wood laminate, on top of insulation boards such as the XPS board. The minimum thickness of any covering material must be 5mm in accordance with IEC 60335-2-96-7.12.1g.

    Technical specifications

    Area7 m²
    Cold lead length3.0 m
    Current4.26 A
    FeaturesWood Finished Floors
    Lifetime warrantyYes
    Mat Length14.0 m
    Mat or kitMat Only
    Mat Width0.5 m
    Resistance @20°C (−5/+10%)54 Ω
    Thermostat ChoiceMat Only
    Wattage980 W

    Product options

    Product downloads

    Harmoni Commissioning Records

    File Size: 255.76 KB

    Harmoni Foil Data Sheet

    File Size: 697.67 KB

    Harmoni Foil Manual

    File Size: 1.97 MB

    Harmoni Installer Warranty

    File Size: 761.86 KB

    Harmoni Lifetime Warranty

    File Size: 760.19 KB
